Strong Performance
Powerful sensorless control
Starting torque of 200%/0.5Hz is produced and provides robust power in the low speed region.
Selectable Rotary/Standstill Auto-Tuning
Standstill auto-tuning is equipped to find motor constant without rotation under conditions where the system is installed or motor cannot rotate.
Flying Start Function
VFD capable for quick reliable smooth restarts into bi-directional rotating loads.
Standard Compliance
Built-in DC Reactor
Effective in improving power factor and decreasing THD.
? 3-phase 400V 30~75kW
Built-in EMC Filter
Meets the electrical noise reduction regulation.
Related standards: 2nd Environment / Category C3
(Class A) CE standard is certified
? C2 : 1-phase 200V 0.4~2.2kW
? C3 : 3-phase 400V 0.4~75kW
Global Compliance (UL, CE)
Global standard compliance
? UL, CE, Gost, C-tick and cUL
Dual Rating Operation
It is designed to choose between heavy and normal duty operation.
Overload capacity
? Heavy duty operation :
150% of rated current, 60 seconds
? Normal duty operation :
120% of rated current, 60 seconds
Various field networks
Able to deal with a variety of field networks Easy maintenance and mounting.
Various field bus options
Profibus, Ethernet IP, Modbus TCP, CANopen Easy to install and use.
Safety Function
Built-in Safety Torque Off (STO)
The Safety input function meets EN ISO 13849-1 PLd and EN 61508 SIL2 (En 60204-1, stop category 0).
This feature is equipped and enables you to meet current safety standards.
